Vegetable Mesh Belt Dryer/Drying Machine

Baixin Vegetable Continuous Mesh Belt Dryer Machine is a kind of continuous production drying equipment, the main heating way has electric heating, steam heating, hot air heating. Its main working principle is to spread the material evenly in the network. The material is moved in the dryer by the operation of the machine, and the hot air draws out the water vapor of the material. so as to achieve the purpose of drying. The operation temperature is 40-120 degree centigrade. And the dry cycle is 1-5 hours. It is mainly used for fruit and vegetable, traditional Chinese medicinal materials and other agricultural and sideline products. The equipment easy to operate, save time, drying process health and protect environment.

Model BX-2*6m BX-2*8m BX-2*9m BX-2*10m BX-2*12m BX-2*15m Areas of dry 4 layers 36㎡ 64㎡ 72㎡ 80㎡ 96㎡ 120㎡ 5 layers 45㎡ 80㎡ 90㎡ 100㎡ 120㎡ 150㎡ 6layers 54㎡ 96㎡ 108㎡ 120㎡ 144㎡ 180㎡ Thickness of the material 50-200mm Operation temperature 40-120℃ Drying time 0.5-5h Motor Power YCT-1.1kw YCT-1.5kw YCT-1.5kw YCt-2.2kw YCT-3kw YCT-5.5kw Evaporation,capacity 300-500 kg/h 430-550 kg/h 500-600 kg/h 560-650 kg/h 620-750 kg/h 1000-1200kg/h The size of input furnace 3.2*1*2.7 3.9*1.26*3 3.9*1.26*3 4.7*1.5*3 4.7*1.5*3 4.7*1.5*3 Fan 8C-11kw 10C-15kw 10C-15kw 11C-22kw 12C-22kw 14C-55kw Exhaust fan 3.15C-1.5kw Y5-47-4C-2.2kw Output conveyor 0.12kw(adjust speed motor) Total power 14.9kw 20.7kw 24.2kw 28.4kw 37.2kw 64.7kw

The dryer machine  has good quality, and both inside and outside dryers are made of stainless steel or paint materials. High temperature resistance, corrosion resistance, high strength, rust-free, suitable for food series, vegetable series, fruit series, pharmaceutical series, agricultural and sideline products of large-scale continuous dehydration drying.
