Dehydrate Fructus aurantii in a Dehydrator/Fructus aurantiiDrying Process
Introduction to fructus aurantii：
The leaves of Fructus aurantii are dark green, the peel is a little thick to very thick, hard to peel, orange yellow to scarlet, the core is solid or semi full, the flesh is sour, sometimes bitter or with special smell, and the seeds are many and large. It is hard and not easy to break.
Fructus aurantii drying process：
The drying room is divided into two channels by using the middle partition, which makes the drying room form a circular structure based on the plane of 360 degrees. Axial convection fan is installed in the inner channel of drying room. The fan must be able to be used in high temperature and humidity environment. If the width of drying room is about 2m, 6-8 fan can be used. If the width of the drying room is about 3 meters, use 8-12 fans. If the drying room is larger than 4 meters, 16 fans are recommended.The main machine of the dryer is equipped with dehumidification fan of no less than 0.75KW to pump wet air into the main machine, and interact with fresh air through waste heat recovery device to realize the first waste heat recovery. Then through the evaporator, the second waste heat recovery is realized. If the drying room area is large, it is recommended to add fresh air valve at the drying room area corresponding to the fan in the drying room.
Add strong exhaust fan (optional, optional). If the drying room has a large area, it is suggested that a strong fan should be added above the drying room corresponding to the main machine in the drying room. After the optimization design of the air path, the dryer has suitable wind force and good temperature uniformity, which can basically meet the production requirements of aurantium aurantium.
The overall drying time of Fructus aurantii is 25-28 hours, which can be extended or reduced according to the thickness and maturity of Fructus aurantii.
Recommendation of fructus aurantii dryer/drying machine
Commercial 100-3000kg/h large amount of dehydration wide application and easy operation
Heat pump drying machine use the principle of inverse Carnot cycle. It absorbs low-temperature heat energy in the air, which becomes high-temperature heat energy after efficient heat collection and integration by the heat pump system, and is transported to the drying room for cyclic heating and drying of materials.It refers to exhausting the hot and humid air in the drying room directly to the outside of the drying room through dehumidification device, and then replenishing natural fresh air.
Hot air circle drying machine belongs to high temperature heat pump unit. Its working principle is: the working fluid of the heat pump is compressed by the compressor, becomes high temperature and high pressure gas, enters the condenser, condenses and liquefies the heat, and is used for air heating in the drying room. The moisture in the material is vaporized and evaporated by the form of hot air, and the evaporated water vapor is discharged by the moisture discharge system, thereby achieving the purpose of drying the drying material.
Fructus aurantii drying video：
