Ginger Processing Process / Ginger Processing Machinery
Ginger Processing Process / Ginger Processing Machinery
Ginger is commonly planted in tropical areas of Asia and Southeast Asia and is widely used in food, beverage, cosmetics and spices. In order to meet the cooking needs of different families, restaurants and food processing plants, ginger needs further deep processing, so as to improve the added value of ginger in ginger planting industry and reduce ginger loss and storage and transportation cost caused by ginger price fluctuation.
If you want to start ginger business, you first need a set of professional ginger processing equipment. Ginger processing capacity is different, and the configured ginger processing machinery is also different. Next, I'll share the process flow of 50-100kg / h small output semi-automatic ginger processing line and 500-800kg / h large output full-automatic ginger processing line.
500-800kg/h large output full-automatic ginger processing line:
Ginger processing line takes ginger as raw material and processes ginger into ginger powder through processing processes such as cleaning, peeling, slicing, drying and grinding. Meet the cooking needs of different families, restaurants and food processing plants.Further processing of ginger can improve the added value of ginger in ginger planting industry and reduce ginger loss and storage and transportation cost caused by ginger price fluctuation. This is the best choice for ginger business!
Ginger processing line flow chart:
The working process of the ginger processing line: ginger cleaning-ginger peeling-ginger slicing-ginger drying-ginger powder grinding-ginger powder packaging
Ginger processing line component:
Ginger cleaning machine: It is used to clean the dirt, dust and other impurities attached to the surface of ginger root. The ginger is rolled, washed and transported under the action of high pressure water flow and powerful air bubbles, and then sent to the next process.
Ginger peeler: for cleaning and removing the epidermis. The specially designed screw feeding structure is adopted to realize fully automatic work.
Ginger slicer: The thickness of ginger slices is uniform, and the slice thickness can be adjusted as needed.
Ginger air dryer: effectively remove the moisture on the surface of ginger slices after cleaning, greatly shorten the drying cycle, suitable for assembly line operation.
Ginger slice dryer: adopts multi-layer moving stainless steel mesh belt, automatic loading and unloading, saving a lot of labor costs. Flexible heat source selection: Coal, wood chips, natural gas, diesel, propane, electricity etc.
Ginger powder making machine: Grind dried ginger slices to a fineness of 10-120 mesh. The ginger grinder is air-cooled or water-cooled and can work continuously for a long time.
Ginger powder packaging machine: Generally speaking, ginger powder business requires automatic ginger powder packaging equipment. The ginger powder packaging machine has a PLC control system, which is intelligent and controllable, and can be quickly adjusted according to customer packaging requirements. Packaging weight and quantity are automatically adjusted.
500-800kg/h automatic ginger processing line parameter ：
| 500-800kg/h automatic ginger processing line | ||||
| Number | Name | Power | Size | Output |
| 1 | Cleaning hoist | 0.37KW | 3200*1050*2500mm | 500-1000kg/h |
| 2 | Bubble cleaning machine | 3.37KW | 3000*1020*1350mm | 1000kg/h |
| 3 | Hoist | 0.55KW | 1500*800*1600mm | 500-1000kg/h |
| 4 | Cleaning and peeling machine | 2.75KW | 3050*700*1600mm | 1000kg/h |
| 5 | Picking table | 0.37KW | 3000*740*1100mm | 500-1000kg/h |
| 6 | Slicer | 1.1KW | 690*560*880mm | 500kg/h |
| 7 | Hoist | 0.55KW | 1500*800*1600mm | 500-1000kg/h |
| 8 | Dryer | 20.12KW | 9000*2000*2500mm | 500-800kg/h |
| 9 | Grinder | 15KW | 1200*1000*2000mm | 500-700kg/h |
| 10 | Packing Machine | 3.5KW | 3000*1500*2600mm | 30-60 packs/min |
| The ginger powder processing line can be equipped according to the user's requirement and the production demands. | ||||
50-100kg/h small output semi-automatic ginger processing line:
Ginger processing line component:
50-100kg/h ginger processing line parameter:
| 50-100kg/h small output ginger processing line | ||||
| Number | Name | Power | Size | Output |
| 1 | Cleaning and peeling machine | 0.75KW | 690*430*860mm | 100kg/h |
| 2 | Slicer | 1.1KW | 690*560*880mm | 300kg/h |
| 3 | Dryer | 3KW | 2100*930*2100mm | 50-100kg/h |
| 4 | Grinder | 5.5KW | 750*600*1260mm | 30-150kg/h |
| 5 | Packing Machine | 1.6KW | 700*750*1650mm | 30-60 packs/min |
| The ginger powder processing line can be equipped according to the user's requirement and the production demands. | ||||
Do you want to start a ginger business? If you want to know the price of ginger processing machinery and more professional questions about ginger processing, please feel free to contact us online!!
Ginger processing line video：
