Ginger Machine/Ginger Processing Machine/Ginger Processing Plant/Ginger Powder Making Machine/Ginger Machine Price
Ginger Machine/Ginger Processing Machine/Ginger Processing Plant/Ginger Powder Making Machine/Ginger Machine Price
Ginger is commonly planted in tropical areas of Asia and Southeast Asia and is widely used in food, beverage, cosmetics and spices. In order to meet the cooking needs of different families, restaurants and food processing plants, ginger needs further deep processing, so as to improve the added value of ginger in ginger planting industry and reduce ginger loss and storage and transportation cost caused by ginger price fluctuation.If you want to start ginger business, you first need a set of professional ginger processing equipment. Ginger processing capacity is different, and the configured ginger processing machinery is also different.
Ginger Processing Machine/Ginger Powder Making Machine
The processing of ginger has a very good development prospect in the world and a huge market. So what are the processing procedures of ginger and how to configure ginger processing machinery. Next, I will share with you the ginger processing production line configured by Baixin Machinery.If you want to start ginger business, you first need a set of professional ginger processing equipment. Ginger processing capacity is different, and the configured ginger processing machinery is also different.
The ginger processing line uses ginger as raw material, and processes ginger into ginger powder through processing techniques such as cleaning, peeling, slicing, drying, and grinding. Meet the culinary needs of different households, restaurants and food processing plants.
Further processing of ginger can increase the added value of ginger in the ginger planting industry, and reduce the ginger loss and storage and transportation costs caused by ginger price fluctuations. This is the best choice for the ginger powder business!
Ginger Processing Plant/Ginger Processing Line Flow Chart:
The working process of the ginger processing line: ginger cleaning-ginger peeling-ginger slicing-ginger drying-ginger powder grinding-ginger powder packaging
Ginger Machine/Ginger Processing Machine Component:
A complete large-scale ginger processing plant mainly includes: ginger cleaning and peeling machine, ginger slicer, dehydrator, ginger dryer, ginger powder grinding equipment, ginger packaging machine, etc., each equipment interacts. Connected by a hoist.
Ginger cleaning machine: It is used to clean the dirt, dust and other impurities attached to the surface of ginger root. The ginger is rolled, washed and transported under the action of high pressure water flow and powerful air bubbles, and then sent to the next process.
Ginger peeler: for cleaning and removing the epidermis. The specially designed screw feeding structure is adopted to realize fully automatic work.
Ginger slicer: The thickness of ginger slices is uniform, and the slice thickness can be adjusted as needed.
Ginger air dryer: effectively remove the moisture on the surface of ginger slices after cleaning, greatly shorten the drying cycle, suitable for assembly line operation.
Ginger slice dryer: adopts multi-layer moving stainless steel mesh belt, automatic loading and unloading, saving a lot of labor costs. Flexible heat source selection: Coal, wood chips, natural gas, diesel, propane, electricity etc.
Ginger powder making machine: Grind dried ginger slices to a fineness of 10-120 mesh. The ginger grinder is air-cooled or water-cooled and can work continuously for a long time.
Ginger powder packaging machine: Generally speaking, ginger powder business requires automatic ginger powder packaging equipment. The ginger powder packaging machine has a PLC control system, which is intelligent and controllable, and can be quickly adjusted according to customer packaging requirements. Packaging weight and quantity are automatically adjusted.
Ginger Processing Line Advantages:
1: Can be customized.Configure different production lines according to customer output requirements.
The ginger production line is fully automatic and semi-automatic, and customers can choose according to their own needs.
2: Easy to operate.
The ginger production line is easy to install and can be used after connecting to the power supply. It is reliable to use and easy to disassemble.
3: Ginger is of high quality.
The dryer adopts medium and low temperature drying. After drying, the original color and nutrients of ginger can be completely retained.
4:Flexible heat source selection of dryer: Coal, wood chips, natural gas, diesel, propane, electricity etc.
5: Wide range of applications:
Most of the machines in the line are not only suitable for ginger, but also for other fruits and vegetables.
Ginger Machine Price/1000kg/h Ginger Processing Line Parameter：
| 1000kg/h automatic ginger processing line | |||||
| Number | Name | Power | Size | Output | Price(Dollar) |
| 1 | Cleaning hoist | 0.37KW | 3200*1050*2500mm | 1000kg/h | 2100 |
| 2 | Bubble cleaning machine | 3.37KW | 3000*1020*1350mm | 1000kg/h | 5000 |
| 3 | Hoist | 0.55KW | 1500*800*1600mm | 1000kg/h | 2100 |
| 4 | Cleaning and peeling machine | 2.75KW | 3050*700*1600mm | 1000kg/h | 2400 |
| 5 | Picking table | 0.37KW | 3000*740*1100mm | 1000kg/h | 2100 |
| 6 | Slicer | 1.1KW | 690*560*880mm | 1000kg/h | 3800 |
| 7 | Hoist | 0.55KW | 1500*800*1600mm | 1000kg/h | 2100 |
| 8 | Dryer | 20.12KW | 9000*2000*2500mm | 800-1000kg/h | 42000-63000 |
| 9 | Grinder | 15KW | 1200*1000*2000mm | 500kg/h | 3000 |
| 10 | Packing Machine | 3.5KW | 3000*1500*2600mm | 30-60 packs/min | 12000 |
| The ginger processing line can be equipped according to the user's requirement and the production demands. | 76600-97600 | ||||
Ginger Machine Price/1000kg/h Ginger Processing Line Parameter：
| 200-300kg/h small output ginger processing line | |||||
| Number | Name | Power | Size | Output | Price(Dollar) |
| 1 | Cleaning and peeling machine | 0.75KW | 690*430*860mm | 500kg/h | 1500 |
| 2 | Slicer | 1.1KW | 690*560*880mm | 300kg/h | 1900 |
| 3 | Dryer | 3KW | 2100*930*2100mm | 200-300kg/h | 7500 |
| 4 | Grinder | 5.5KW | 750*600*1260mm | 150kg/h | 2000 |
| 5 | Packing Machine | 1.6KW | 700*750*1650mm | 30-60 packs/min | 8000 |
| The ginger processing line can be equipped according to the user's requirement and the production demands. | 20900 | ||||
Do you want to start a ginger business? If you want to get the ginger powder making machine price and more professional questions about ginger processing machine, please feel free to contact us online!!
Ginger Processing Line Video：
