Dehydration Machine for Food

Dehydrated food has always been a big category in the food market with a lot of potential. With the development of technology, food dehydrated has made great progress in both product types and dehydrated technology. The types of dehydrated food on the market are becoming more and more diverse, and the quality of dehydrated food is getting better and better. The food dehydrated industry has also become an industry with very good development prospects. Next, I will introduce some of the most common dehydration Machine for Food in the food dehydrated industry produced by Baixin Machinery.

Dehydration Machine for Food now have continuous mesh belt dehydration Machine for Food, heat pump electric food dehydration room, microwave dehydration Machine for Food and all-in-one dehydration Machine for Food. These four types of food dehydrations have their own advantages, and the applicable dehydrated requirements are also different. The specific information is as follows.

1.Continuous Mesh Belt Dehydration Machine for Food

The first is continuous mesh belt dehydration Machine for Food. It can achieve continuous production, and the output can reach 300-2000kg/h. The main heating methods are electric heating, steam heating, hot air heating, the heat source can be coal, wood chips, natural gas, diesel, propane, electricity, etc.

Working Principle of Continuous Mesh Belt Dehydration Machine for Food

Its main working principle is to spread the material evenly in the network. The material is moved in the dehydration by the operation of the machine, and the hot air draws out the water vapor of the food. so as to achieve the purpose of dehydration. The operation temperature is 40-120 degree centigrade. And the dehydrate cycle is 1-5 hours.

Components of Continuous Mesh Belt Dehydration Machine for Food

The components of this continuous mesh belt dehydration Machine for Food include: Homogenizer, Feeder Conveyor, Mesh belt food dehydration host, Heat source,Air Intake System, Control panel, Observation door, Output conveyor.

Advantages of Continuous Mesh Belt Dehydration Machine for Food

Its advantage is that the speed of dehydrated food is relatively fast, and it can work continuously and uninterruptedly, so as to achieve large-scale production. Other than that, it's very flexible, it's easy or without installation, so you don't have to worry about installation.

2.Microwave Dehydration Machine for Food

This one is microwave dehydration Machine for Food. Its output is 100-2000kg/h. The dehydrated time is 2-5min.

Working Principle of Microwave Dehydration Machine for Food

Microwaves are electromagnetic waves at a frequency of 300 MHz to 300 GHz.The material in the heating medium in the molecules of water is a polar molecule. It is the rapidly changing under high-frequency magnetic field, its polarity orientation will be with the change of external electric field changes, resulting in molecular motion and friction between the effect, this field of the microwave field can be transformed into thermal energy within the medium, the temperature of the material increased, heating and puffing a series of physical and chemical processes, to achieve the purpose of microwave heating and dehydrated. During the equipment is working the microwave generator produces the microwave. The materials enter into the heating chamber by conveyor. At this time, moisture and bacteria inside the material evaporate under the action of microwave energy to achieve unfreeze sterilization ripening fixing dehydrated purpose.

Components of Microwave Dehydration Machine for Food

The microwave dehydration Machine for Food mainly has six components,Microwave Chamber, Water Tower, PLC Control Panel, Feeding Part, Conveyor, Monitoring Window.

Advantages of Microwave Dehydration Machine for Food

1:Fast processing efficiency:
It takes about a few minutes to complete the process from feeding to discharging. The processing efficiency is fast and the effect is good。
2:Uniform dehydrated effect。
The microwave dehydration can make all parts of the material have the same effect.
3:Dehydrated and sterilizing simultaneously, tunnel type design, cover small area, continuous production，
4:Clean and sanitary: it will not pollute the material, nor change the color, fragrance, and nutritional content of the material.

3.Heat Pump Food Dehydration Room

This is heat pump food dehydration room. Its output is 100-5000kg/batch, and the heat source can be electricity, coal, wood chips, natural gas, diesel oil, and propane, etc.

Working Principle of Heat Pump Food Dehydration Room

It adopts the principle of reverse Carnot cycle. It absorbs low-temperature heat energy in the air, and becomes high-temperature heat energy after efficient heat collection and integration of the heat pump system, which is transported to the dehydrator room to circulate heating and dehydrator the food, and the hot and humid air in the dehydrator room is directly discharged to the outside of the dehydrator room through the dehumidifier.

Components of Heat Pump Food Dehydration Room

The components of this heat pump food dehydration room include: Heat Pump, Trolley Tray, Fan Frame with Fan(Axial Compressor Fan), Dehydration Room Parts.

Advantages of Heat Pump Food Dehydration Room

The advantage of this heat pump food dehydration room is that it can quickly remove the water in the food without affecting the original color, shape and nutrient content of the food. The food heat pump dehydration room is equipped with a computer control system, which can realize automatic temperature control. The dehydrated temperature range of the heat pump dehydration is 20-80°C. It has the advantages of strong dehydrated capacity, better dehydrated effect, simple operation, and 70% energy saving by adopting a heat pump system.

4.All-in-one Dehydration Machine for Food

This all-in-one dehydration Machine for Food has a smaller output among the four dehydration Machine for Food. Its output is 100-1500kg/batch. The heat source is mainly electricity, and it can also be coal, wood chips, natural gas, etc.

Working Principle of All-in-one Dehydration Machine for Food

Dehydrated is take moisture away. But takes away the moisture temperature is not the most critical factor. The key for dehydrated is depending on relative humidity within certain space, Baixin company took advantage of the dehydrated essence, originality developed a“Closed Cycle" dehydrator, changed the traditional heat pump dehydrator "bake" to “dehumidifier”.

Components of All-in-one Dehydration Machine for Food

The components of this all-in-one dehydration Machine for Food include:Power jack, Water outlet, Exhaust air outlet, Supporting wheels, Controller(PLC control panel), Door lock, Observation window, Circulating Air Inlet, Outlet for hot and dehydrate air, PP tray, Stainless steel tray, Supporting racks for trays.

Advantages of All-in-one Dehydration Machine for Food

The new dehydrator All-in-One food dehydrator machine has a compact structure, great energy-saving, wide application, high dehydrated quality, easy operation, simple installation, and movable. It is the best dehydrator equipment for small firms, dehydrated experiments, and scientific research. The uses only connect the power to use, is the easiest operation heat pump food dehydrator machine. Hot air only circulates inside and no energy is lost. The energy-saving is incomparable to traditional dehydrators. Gentle dehydrated at middle and low temperature, Aroma, appearance, and bioactivity are largely retained.

These four are the most commonly used dehydration Machine for Food on the market. They each have their own advantages and are suitable for dehydrated various food. In addition, our dehydration Machine for Food can be customized according to customer needs. If you are interested in our food dehydrations, please feel free to contact us. We will recommend the most suitable food dehydrations for you according to your situation.
